NSN 5306-01-332-7198
Coaxial Connector
Between 1.642 inches and 1.672 inches fastener length, dished hexagon head style, between 0.110 inches and 0.125 inches head height, width between flats: between 0.367 inches and 0.376 inches .
Manufacturer part number NAS6703-21 for national stock number 5306013327198.
Datasheet
-
Product description
Shear Bolt NSN 5306-01-332-7198.
-
MPN or Model
NAS6703-21
-
Schedule B
7318.15.2000 (Bolts and bolts and their nuts or washers exported in the same shipment) -
NMF (National Motor Freight)
093486 - Bolts, Nuts Or Screws, NOI (sub 3) -
Unit Weight (Est.)
0.1 lb -
Thread Class
3a -
Thread Direction
Right-hand -
Thread Length
Between 0.320 inches and 0.370 inches -
Fastener Length
Between 1.642 inches and 1.672 inches -
Head Style
Dished hexagon -
Head Height
Between 0.110 inches and 0.125 inches -
Width Between Flats
Between 0.367 inches and 0.376 inches -
Grip Diameter
Between 0.1890 inches and 0.1895 inches -
Thread Diameter
0.190 inches -
Grip Length
Between 1.302 inches and 1.322 inches -
Thready Qty Per Inch (tpi)
32 -
Min. Tensile Strength (psi)
160000 pounds per square inch -
Surface Finish
32.0 microinches threads -
Material
Iron alloy 660 -
Material Specification
Ams 5731 assn standard single material response or ams 5737 assn standard single material response -
Surface Treatment
Cadmium and chromate -
Surface Treatment Specification
Qq-p-416, type 2 cl 2 federal specification single treatment response -
Thread Series Designator
Unjf -
Specification Data
80205-nas6703 professional/industrial association standard
More from these suppliers
- 5940-00-725-9498 MPN NAS707C2Stud Terminal
- 5940-01-447-2950 MPN NAS1063C3-504BETerminal Board Marker Strip
- 5305-00-008-5891 MPN NAS1102E08-18Machine Screw
- 5305-00-008-7864 MPN NAS1631C2Machine Screw
- 5305-00-012-0719 MPN NAS1635-00-8Machine Screw
- 5305-00-068-7047 MPN MS24694A8Machine Screw
- 5305-00-071-1322 MPN MS51960-65Machine Screw
- 5305-00-078-8606 MPN NAS560HK3-15Machine Screw
A high strength, 160,000 pounds per square inch (1100 megapascals) minimum tensile strength externally threaded fastener designed for use in applications involving great shear stress. The head is designed to accommodate an external wrench or driver. The head is not designed to be held or driven with an inserted driver, nor is it designed for rotation by the thumb and fingers. The unthreaded portion is of specific grip length, plated or unplated, and is machined to a tolerance of one thousandth (0.001) of an inch (0.025 mm) or less of a specific diameter for items one inch (25 mm) or less in diameter. Items over one inch (25 mm) in diameter shall have a tolerance of fifteen ten thousandths (0.0015) of an inch (0.038 mm) or less. The nominal major diameter of the threads shall be at least one thousandth (0.001) of an inch (0.025 mm) below the minimum shank diameter, but not below the minimum major diameter for applicable class of fit, as shown in the screw thread standards, fed std h28 and/or other nationally recognized standards. A locking feature may be incorporated in the design of the head or threads. See bolt, machine and bolt, clevis.
Pricing and Availability
Get a quote for 5306-01-332-7198 shear boltManufacturer Part Numbers and Alternates
MPN manufacturer part number | Registrant or Supplier |
---|---|
NAS6703-21 | National Aerospace Standards |
